Guitar Neck Design With Carbon Fiber

Carbon Fiber Guitar Neck ReinforcementThere are many different design variations for effectively using carbon fiber. The factors that may guide you in finding the best layout for you guitar might include, the neck profile, thickness, string tension, woods used for the neck or fingerboard, and other factors.

You probably know that we get the best stiffness from a material by making it taller (as opposed to wider). So it’s a good idea to use the tallest carbon fiber bars you can that will safely fit within the design requirements of your guitar neck.

Here is the way it works out for me; I put my truss rod in the center and then leave ⅛” of neck wood on either side of the truss rod channel. Then I route my channels for the carbon fiber rods into the neck blank at a depth that is .020” deeper than the height of the carbon fiber bars. In my case I’m using the bars from Stew Mac that measure .25” tall, so my channels are cut to a depth of .27”.

Carbon Fiber Guitar Neck Elevated FingerboardI do this so that I can glue in a filler strip of wood over the top of the carbon fiber bars in order to make sure that my fingerboard is glued in place with a wood to wood joint everyplace along it’s surface. I do this to ensure a good glue joint and also to ensure evenness of tone all over the fingerboard. I also find that inlaying the carbon fiber bars as deep as possible into the neck results in more stiffness too.

Carbon Fiber Guitar Neck Layout

stew mac carbon fiberOn the right are a few photos from an article you might want to check out over at Stew Mac showing and discussing some different carbon fiber reinforced neck layouts. Click the preceding link or click on the photos to view that article.

You do need to make some drawings though and be sure that you will not hit those bars as you carve your neck profile, so take time to make sure your design is solid and your measurements and calculations are correct.

Elevated Fingerboard & Neck Extension

One other aspect of designing your carbon fiber reinforced guitar neck is thinking about the portion of the fingerboard that extends out over the body of the guitar.

I like to use an elevated fingerboard design for archtops, steel string, and nylon string guitars to help the fingerboard surface stay stable and have the proper shape for optimum setup and playability as well as stability over time.

The elevated fingerboard also gives me a nice way to extend the carbon fiber out over the body of the guitar for stability, set up, and evenness of tone.

IMG_0964
